Το Chartwell Derek Hughes LS6F ειναι ζευγος ηχειων 2 δρομων δαπεδου, με 1x 6.5" polypropylene woofer και 1x 0.75" silk dome tweeter. Η σχεδιαση της καμπινας ακολουθει την αγγλικη σχεδιαστικη λογικη "thinwall".

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων, ανταλλαγων.

Building on the success of our popular LS6 monitor, the LS6/f is a floor-standing loudspeaker system that combines a modern aesthetic with the open, uncoloured sound you'd expect from a Graham Audio system.

The integrated plinth provides a flow-optimised path for the airflow from the port, reducing distortion at high outputs.

The LS6/f uses the same custom drive units as the stand-mount LS6 and has an optimised crossover network using premium quality components to integrate the acoustic output from both drive units and equalise the overall response for optimum performance in free space. A switch on the front panel adds 1 or 2dB to the tweeter level, which might be advantageous in certain acoustic environments.

In common with all our loudspeakers, the cabinet uses the classic BBC "thinwall" construction, where the panels are mass-loaded to ensure that resonances are moved away from the critical mid-range region, and a layer of Rockwool is held in place by fabric to provide air damping.

Hand-matched veneers are applied and finished to a very high standard. The grille is carefully designed to minimise diffraction effects and is held in place by concealed rare-earth magnets.

Specifications

• Colour  Cherry, Ebony, Oak, Rosewood, Walnut
• Operating Principle 2 way, Bass reflex
• Speaker Drivers 1 x 165mm polypropylene bass, 1 x 0.75" soft dome tweeter
• Impedance 8 Ω
• Frequency Response 40 Hz – 20 kHz ±3 dB
• Sensitivity 87 dB
• Maximum Output Over 100 db for a pair at 2m
• Recommended Amplifier Power 50 W – 150 W
• Construction Birch plywood, Thin wall construction
• Dimensions (WxDxH) 960 mm x 320 mm x 320 mm (including plinth)
• Weight 21 kg each
• Warranty 5 years
