Το REL Reference No36 ειναι ενα ενεργο υπογουφερ με 1x 15" carbon fibre woofer, με ενσωματωμενο ενισχυτη class AB/D 1000wrms. Δυναται να συνδεθει ασυρματα μεσω REL AirShip Direct.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Driver
To meet the demands of No.36’s 1,000-watt RMS Class AB/D amplifier, the cone structure has been reinforced and the suspension revised to permit greater travel while maintaining control. Carbon fibre locking shells and larger full-ring terminals transfer the immense current available from the amplifier with complete confidence.

Amplifier
No.36's 1,000-watt RMS Class AB/D amplifier was developed to give its 15-inch Pure Carbon Fibre driver extraordinary reserves of speed, control, and dynamic freedom. It delivers immense current precisely when the performance demands it, then settles instantly as the music returns to silence.

Its efficiency allows No.36 to deliver breathtaking scale without the excess heat and power consumption associated with a conventional amplifier of this output. More importantly, it maintains composure at every level, preserving texture, timing, and spatial detail even during the most demanding passages.

Line Array
For more than two decades, REL Reference Line Arrays have represented the ultimate expression of our approach to deep bass. No.36 advances that tradition with greater current, increased driver capability, and a more rigid, precisely adjustable cabinet, delivering deeper extension, greater drive, and increased output from every unit.

But a Reference Line Array is about far more than output. By vertically distributing multiple subwoofers through the height of the room, the array energizes the space in a fundamentally different way, allowing the main loudspeakers to perform with greater freedom and scale. The transformation extends beyond bass: the soundstage opens, dynamics become more effortless, and midrange and high-frequency performance gain clarity and dimensionality.

Because No.36 retains the dimensions of previous 15-inch Reference models, it can also anchor existing arrays incorporating No.32 or No.25, providing a natural upgrade path for longtime Reference owners. With No.36 anchoring the array, REL’s most ambitious systems reach a new level of scale, precision, and authority.

Wireless
Optional AirShip Direct delivers REL’s renowned High Level Input and .1/LFE signals wirelessly, with zero digital compression and no compromise in sound quality. High Level and .1/LFE can be used simultaneously, allowing No.36 to integrate seamlessly for music while delivering the full impact of film soundtracks, without the need for long cable runs.

Designed to plug directly into the rear panel, AirShip Direct keeps installation clean and virtually invisible while preserving the speed, transparency, and natural character expected from REL Reference.

Remote
The REL Reference Remote is designed with the same attention to detail as No.36 itself. Its sculpted form sits naturally in the hand, while its substantial weight and beautifully finished controls convey the quality and permanence expected of a Reference product.

More importantly, it places every critical setup control exactly where it belongs: in the listening chair. High Level or Low Level gain, crossover, .1/LFE gain, phase, and Dual Parametric EQ can all be adjusted while listening to the system. Once setup is complete, the remote can be switched off to lock the settings and prevent accidental changes.

Dual Parametric EQ provides precise control across the bass range, allowing deep room resonances to be corrected while upper-bass excess can be gently trimmed. The result is deeper, cleaner bass and seamless integration with the main loudspeakers, all without leaving your seat.

Specifications

• Type: Closed box, front-firing driver
• Active Driver Size & Material: 15" (380 mm) long-throw, carbon fiber cone with inverted carbon fibre centre cap
• Passive Radiator Size & Material: N/A
• Low Frequency Extension: -6dB at 15Hz in-room
• Input Connectors:
  • High Level: Neutrik SpeakON
  • Low Level: Stereo RCA and XLR
  • LFE: RCA and XLR
• Output Connectors:
  • High Level: Neutrik SpeakON
  • LFE: RCA and XLR
  • Line: XLR and RCA
• Power Output: 1000W RMS, Ultra High-Current Power Supply
• Amplifier Type: Class AB/D
• Wireless Capability: REL AirShip Direct (sold separately)
• Dual Parametric Filter: Yes
• Finish: Piano Black Lacquer, 12 coats
• Protection System:
  • Fully Electronic Set Safe: Yes
  • D.C. Fault Protection: Yes
  • Output Short Protection: Yes
• Mains Input Voltage: 220–240V / 110–120V for certain markets
• Fuses: 8A semi-delay, 230V operation
• Supplied Accessories:
  • Mains Lead: Yes
  • Neutrik SpeakON: 10m nominal
  • User Manual: Yes
• Dimensions (W x H x D): 74,3 x 54,1 x 81,6 cm
• Shipping Dimensions (W x H x D): 98,7 x 76,8 x 93,2 cm
• Net Weight: 91.8kg
• Shipping Weight: 105.7kg
