Το Martin Audio CDD8 ειναι επαγγελματικο ηχειο 8Ω, 2 δρομων με 1x 8" woofer και 1x 1" polyimide dome tweeter.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

The CDD8 is an ultra-compact two-way passive loudspeaker system with an integrated 8” (200mm) LF/1” (25mm) exit HF Coaxial Differential Dispersion driver which can be easily rotated for horizontal or vertical orientation depending on venue design requirements. Its small size gives no indication of its high output capability. As a stand-alone loudspeaker, it has a multitude of applications and can also be incorporated as an infill loudspeaker in distributed systems using larger CDD models, such as the CDD12 and CDD15.

Applications

• Live Music Clubs and Bars
• Nightclubs
• Bars and Restaurants
• Museums and AV Spaces
• Convention Centres
• Hotels
• Retail Outlets
• Leisure Centres
• Houses of Worship

Features

• Ultra-Compact, CDD™ passive two-way system
• Coaxial Differential Dispersion™ technology
• Elegant ABS moulded enclosure
• User-rotatable coaxial drive unit
• Vertical and horizontal mounting options
• Screw-free perforated steel grille
• 8Ω nominal impedance
• Discreet mounting accessories
• Black or white standard colour options

Specifications

• Type: Ultra-compact, coaxial Differential Dispersion passive two-way system
• Frequency Response: 70 Hz - 20 kHz (±3 dB), -10 dB @ 55 Hz
• Driver:
  • LF: 8" (200 mm) / 2? (50 mm) voice coil, long excursion, shared ferrite motor system with HF
  • HF: 1" (25 mm) exit / 1.4" (38 mm) voice coil, polyimide dome compression driver
• Rated Power: 200 W AES, 800 W peak
• Sensitivity: 94 dB
• Maximum SPL: 117 dB continuous, 123 dB peak
• Nominal Impedance: 8 Ω
• Dispersion (-6 dB): 110°?80° horizontal, 60° vertical (user-rotatable)
• Crossover: 2.3 kHz passive
• Enclosure: 14 litre composite material
• Finish: Black or white textured paint
• Protective Grille: Perforated steel with scrim cloth backing (black or white)
• Connectors: Low-profile 13A push-lock
• Pin Connections: Input+, Input -, Link -, Link +
• Fittings: 6 ? M6 inserts for wall / ceiling brackets
• Dimensions (W ? H ? D): 25.6 ? 41.0 ? 25.2 cm
• Weight: 9.5 kg
