Το Rega Fono MC mk4 ειναι ενα phono stage MC.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Key Features

• Dedicated moving coil phono stage
• Simple connectivity and operation
• Fully adjustable via DIP switches located on the rear panel
• MUSE operational amplifier used in RIAA equalization amplifier
• Two selectable gain settings
• Default factory settings matched for all Rega MC models

Specifications

• Output Impedance: 200 Ω
• Recommended Minimum Output Load Resistance: 5 kΩ
• Frequency Response (50 kΩ load): 13 Hz (-3 dB) – 100 kHz (-0.3 dB)
• RIAA Accuracy (50 kΩ load): Better than ±0.2 dB (100 Hz – 100 kHz)
• Power Requirements: 24 V AC / 150 mA (max)

• Load Settings (Adjustable MC Stage)
  • Input Sensitivity (for 200 mV output)
    • 4 off: 133 µV
    • 4 on: 67 µV
  • Input Loading Resistance
    • 1 & 2 off: 400 Ω
    • 1 on: 100 Ω
    • 2 on: 150 Ω
    • 1 & 2 on: 70 Ω
  • Input Loading Capacitance
    • 3 off: 1000 pF
    • 3 on: 4300 pF
  • Gain (at 1 kHz)
    • 4 off: 63.5 dB
    • 4 on: 69.5 dB
  • Maximum Input Level (at 1 kHz)
    • 4 off: 6.7 mV
    • 4 on: 3.4 mV
  • Factory Settings for Rega MC Cartridges
    • Impedance: 100 Ω
    • Capacitance: 1000 pF
    • Gain: High
