Οι Tsakiridis Devices Achilles Ultima ειναι ζευγος τριοδικων τελικων μονφωνικων ενισχυτων class A, ισχυος 2x8 Watts με 300B. Σε σχεση με τον Achilles Ultra, διαθετει πυκνωτες Mundorf Supreme Silver Gold Oil,  Rike Ausdio QCap4 Copper Oil, μεταχηματιστες 16 τυλιγματων απο χαλκο υπερυψηλης καθαροτητας 6Ν και ασημοκολληση WBT παντου.

Εγγυηση Αντιπροσωπειας. Δυνατοτητα δοσεων.

Achilles Ultima is a power amplifier in monoblock configuration. It’s design is a class A 300B triode amplifier with mu-stage driving circuit.
All electronic components are through hole type silver soldered by hand. Achilles Ultima utilizes our top of the line 16 layer handmade output transformers with high quality core for superior sound quality.

The 8W of power per channel of Achilles requires high sensitivity loudspeakers to enjoy your music. The triode class A configuration of the 300B with the high linearity of the preamplification stage offer an unsurpassed audio experience to every audiophile.
Gold plated RCA connectors are implemented for the signal input and WBT-710 Next Gen binding posts for the loudspeakers.

Carefully selected values and types of the electronic components contribute to the reliable circuits operation and the high sound quality of the amplifier. Premium quality oil capacitors (Mundorf Supreme Silver Gold Oil – Rike Ausdio QCap4 Copper Oil) on the signal path and premium quality tubes are used in Achilles Ultima.

The meticulous PCB design ensures excellent behavior in SNR and distortion.
Inner signal wiring with high quality shielded signal cable. Power wiring uses high quality copper cables of more-than-needed AWG gauge, to achieve low impedance power transfer. All power cables are twisted in pairs to minimize the electromagnetic interference.

The handmade 16 layer output transformers with high quality copper wire and core material enable the amplifier to reveal an excellent sound stage and the slightest music details through the entire audio spectrum to give you a unique audio experience.
Made by us and tested thoroughly for quality and reliability. The same applies to the power transformer. The positioning of the transformers is such that minimizes the magnetic coupling between power and output transformers.

Features

• Inputs: 1 line input
• Input connectors: RCA gold plated
• Speaker connectors: WBT-0710 Next Gen
• Power supply capacitors: High quality Long life Capacitors
• Signal capacitors: High quality Oil Capacitors (Mundorf / Rike Audio)
• Power resistors: Carbon film 5% tolerance
• Power transformer: Handmade 250W each unit
• Output transformer: Handmade 16 layer 6N copper high quality core
• Driving stage tubes: premium quality 1x6SL7, 1x EL34 each unit
• Power tubes: premium quality 1x300B each unit

Specifications

• Output Power: 2x8W
• Input impedance: 100 kOhm
• Output impedance: 6 Ohm
• Input sensitivity: 1V
• Signal to Noise Ratio (SNR): 83db
• Rise time: 4us at 10kHz
• Harmonic distortion: 2W at 1kHz 0.40%
• Frequency response: -3db 10Hz-57000Hz
• Power supply energy: 80 Joule each unit
• Power consumption: 95W each unit
• Weight: 4.5kgr each unit
• Dimensions (WxDxH): 17x43x22 cm
